Specifications
- Besleme Gerilimi
- 5V
- Number Of Da Converters
- 4
- Fonksiyon Sayısı
- 1
- Min Supply Voltage
- 2.7V
- Reference Type
- External
- Terminal Kaplaması
- Tin/Silver/Copper (Sn/Ag/Cu)
- Data Interface
- SPI
- Montaj
- Surface Mount
- Voltage Supply Analog
- 2.7V~3.3V 5V
- Integral Nonlinearity Inl
- 4 LSB
- RoHS Durumu
- ROHS3 Compliant
- ECCN Kodu
- EAR99
- Input Format
- SERIAL
- Power Consumption
- 3.6mW
- Power Supplies
- 3/5V
- Ambalaj
- Tape & Reel (TR)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Supply Type
- Analog, Digital
- Conversion Rate
- 102 ksps
- Analog Output Voltagemax
- 5.1V
- Kılıf / Paket
- 16-UFBGA, WLCSP
- Terminal Pozisyonu
- UPPER
- Temel Parça No
- TLV5614
- Kurşunsuz
- Lead Free
- Max Supply Voltage
- 5.5V
- Inldnl Lsb
- ±1.5, ±0.5
- Max Power Dissipation
- 8mW
- Differential Output
- No
- Linearity Errormax El
- 0.0977%
- JESD-609 Kodu
- e1
- Tepe Reflow Sıcaklığı (°C)
- 260
- Montaj Tipi
- Surface Mount
- Converter Type
- D/A CONVERTER
- Terminal Sayısı
- 16
- Settling Time
- 20μs
- Input Bit Code
- BINARY
- Pin Sayısı
- 16
- Nominal Supply Current
- 3.8mA
- Voltage Supply Digital
- 2.7V~3.3V 5V
- Çıkış Tipi
- Voltage - Buffered
