Specifications
- Terminal Adımı
- 2.54mm
- Qualification Status
- Not Qualified
- Besleme Gerilimi
- 3V~5.25V
- Low Power Mode
- NO
- Montaj
- Through Hole
- Kılıf / Paket
- 40-DIP (0.600, 15.24mm)
- Number Of Serial Ios
- 1
- HTS Kodu
- 8542.31.00.01
- Maks. Oturma Yüksekliği
- 5.08mm
- Kurşunsuz
- Contains Lead
- Boundary Scan
- NO
- Operating Supply Voltage
- 5V
- Ambalaj
- Tube
- Min. Çalışma Sıcaklığı
- 0°C
- Additional Feature
- ALSO OPERATES AT 3.3V SUPPLY AT 14.9 MHZ
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 52.455mm
- Nominal Supply Current
- 10mA
- Pin Sayısı
- 40
- Ram Words
- 0
- Upsucsperipheral Ics Type
- SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Temel Parça No
- TL16C550
- Clock Frequency
- 16MHz
- Pin Sayısı
- 40
- Data Rate Max
- 1Mbps
- Montaj Tipi
- Through Hole
- Communication Protocol
- ASYNC, BIT
- Genişlik
- 15.24mm
- With Modem Control
- Yes
- Number Of Channels
- 1, UART
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- External Data Bus Width
- 8
- Data Encodingdecoding Method
- NRZ
- Maks. Çalışma Sıcaklığı
- 70°C
- Kurşunsuz Kodu
- no
- Parça Durumu
- Obsolete
- Data Transfer Ratemax
- 0.125 MBps
- Temperature Grade
- COMMERCIAL
