Specifications
- Terminal Formu
- NO LEAD
- Number Of Bits Per Element
- 8
- ECCN Kodu
- EAR99
- Uzunluk
- 2.5mm
- Terminal Sayısı
- 16
- Packing Method
- TR
- Output Polarity
- TRUE
- JESD-609 Kodu
- e4
- Propagation Delay Tpd
- 300 ns
- Load Capacitance
- 50pF
- Count Direction
- RIGHT
- Terminal Pozisyonu
- QUAD
- Logic Type
- Shift Register
- Parça Durumu
- Active
- Montaj
- Surface Mount
- Lifecycle Status
- ACTIVE (Last Updated: 2 days ago)
- Prop Delaynomsup
- 34 ns
- Seri
- 74HC
- Supply Voltagemin Vsup
- 2V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal Adımı
- 0.4mm
- Kılıf / Paket
- 16-XFQFN Exposed Pad
- Kurşunsuz
- Lead Free
- Logic Function
- Shift Register
- Schmitt Trigger
- No
- Pin Sayısı
- 16
- Additional Feature
- PARALLEL OUTPUT IS REGISTERED; UNREGISTERED SERIAL SHIFT RIGHT OUTPUT
- Genişlik
- 2.5mm
- Çalışma Sıcaklığı
- -55°C~125°C
- Besleme Gerilimi
- 5V
- Çıkış Tipi
- Tri-State
- Fmaxmin
- 25 MHz
- Function
- Serial to Parallel
- Besleme Gerilimi
- 2V~6V
- Reach Svhc
- No SVHC
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Output Characteristics
- 3-STATE
- Kurşunsuz Kodu
- yes
- Ambalaj
- Tape & Reel (TR)
- Supply Voltagemax Vsup
- 6V
