PTH08T230WAS

Specifications

Input Voltagenom

5V

Montaj Tipi

Surface Mount

Seri

PTH08T230W

Efficiency

95%

Yüzey Montaj

NO

Protections

OUTPUT OVER CURRENT;THERMAL

Terminal Sayısı

10

Lifecycle Status

ACTIVE (Last Updated: 1 day ago)

Fonksiyon Sayısı

1

Control Mode

VOLTAGE-MODE

Voltage Input Min

4.5V

Tip

Non-Isolated PoL Module

Nem Hassasiyeti (MSL)

3 (168 Hours)

Parça Durumu

Active

Isolation

Non-Isolated

Yükseklik

341μm

Depth

15.75mm

Applications

ITE (Commercial)

Current Output1

6A

Fabrika Tedarik Süresi

6 Weeks

ECCN Kodu

EAR99

Trimadjustable Output

YES

Min Output Voltage

690mV

Thickness

7.5mm

Özellikler

Remote On/Off, OCP, OTP, UVLO

RoHS Durumu

Non-RoHS Compliant

Power Rating

33W

Max Output Voltage

5.5V

Kurşunsuz

Contains Lead

Temel Parça No

TH08T230

Boyut / Ölçü

0.75Lx0.62W x 0.36 H 19.1mmx15.7mmx9.1mm

Contact Plating

Lead, Tin

Output Power

33W

Output Current

6A

Kılıf / Paket

10-SMD Module

Max Power Dissipation

33W

Ambalaj

Tray

HTS Kodu

8504.40.85.00

Number Of Outputs

1

Additional Feature

REMOTE SHUTDOWN
