Specifications
- Operating Temperaturemax
- 85 °C
- Temperature Grade
- INDUSTRIAL
- Control Mode
- VOLTAGE-MODE
- Seated Heightmax
- 0.8 mm
- Jesd30 Code
- R-XQCC-N24
- Fonksiyon Sayısı
- 1
- Additional Feature
- ALSO HAS CONTROL TECHNIQUE OF PFM, ALSO OPERATES AS LDO REGULATOR
- Terminal Kaplaması
- MATTE TIN
- HTS Kodu
- 8542.39.00.01
- Yüzey Montaj
- YES
- Part Life Cycle Code
- Transferred
- Number Of Terminals
- 24
- Switching Frequencymax
- 2000 kHz
- Switcher Configuration
- BUCK
- Moisture Sensitivity Levels
- 1
- Switchingfrequency
- 2 MHz
- Package Body Material
- UNSPECIFIED
- Output Power
- 1.43 W
- JESD-609 Kodu
- e3
- Input Voltagenom
- 3.6 V
- Control Technique
- PULSE WIDTH MODULATION
- Genişlik
- 4 mm
- REACH Uyumluluk Kodu
- compliant
- Uzunluk
- 5 mm
- Operating Temperaturemin
- -40 °C
- Package Style
- CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
- Analog Ic Other Type
- SWITCHING REGULATOR
- Output Voltagenom
- 1.2 V
- Package Shape
- RECTANGULAR
- Output Currentmax
- 1.5 A
- Tepe Reflow Süresi (maks. sn)
- 40
- Package Equivalence Code
- LCC24,.16X.2,20
- Package Description
- HVQCCN, LCC24,.16X.2,20
- Ihs Manufacturer
- NATIONAL SEMICONDUCTOR CORP
- ECCN Kodu
- EAR99
- RoHS
- Non-Compliant
- Number Of Channels
- 4
- Qualification Status
- Not Qualified
- Pin Sayısı
- 24
- Input Voltagemin
- 2.7 V
