Specifications
- Terminal
- SMD/SMT
- Genişlik
- 4mm
- Kılıf / Paket
- 16-WFQFN Exposed Pad
- Reach Svhc
- No SVHC
- Dimming
- Analog, PWM
- Terminal Pozisyonu
- QUAD
- JESD-609 Kodu
- e0
- Applications
- Backlight
- Pin Sayısı
- 16
- Quiescent Current
- 1.9mA
- Min Input Voltage
- 2.5V
- Internal Switchs
- Yes
- Besleme Gerilimi
- 3.6V
- Max Supply Voltage
- 5.5V
- Power Supplies
- 3/5V
- Temel Parça No
- LM3503
- Fonksiyon Sayısı
- 1
- Pin Sayısı
- 16
- Terminal Kaplaması
- Tin/Lead (Sn/Pb)
- Montaj Tipi
- Surface Mount
- Parça Durumu
- Obsolete
- Maks. Oturma Yüksekliği
- 0.8mm
- Montaj
- Surface Mount
- Output Current
- 20mA
- Terminal Sayısı
- 16
- Max Input Voltage
- 5.5V
- Tepe Reflow Sıcaklığı (°C)
- 260
- Switchingfrequency
- 1MHz
- Max Output Voltage
- 44V
- Number Of Segments
- 10
- Çalışma Sıcaklığı
- -40°C~85°C TA
- Min Supply Voltage
- 2.5V
- Topology
- Step-Up (Boost)
- Çıkış Gerilimi
- 44V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Radyasyon Dayanımı
- No
- Number Of Outputs
- 2
- Terminal Adımı
- 0.5mm
- Kurşunsuz Kodu
- no
- ECCN Kodu
- EAR99
