Volume pricing
- 1+ pcs$3.08
- 10+ pcs$2.91
- 100+ pcs$2.74
- 500+ pcs$2.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Turn On Delay Time
- 2.5 ns
- Kılıf / Paket
- 8-WDFN Exposed Pad
- Montaj
- Surface Mount
- Max Power Dissipation
- 1.025W
- Operating Supply Voltage
- 3.3V
- Interface Standards
- EIA-644; TIA-644
- Power Consumption
- 18W
- Thickness
- 800μm
- Pin Sayısı
- 8
- Besleme Gerilimi
- 3.3V
- Max Supply Current
- 9mA
- Fonksiyon Sayısı
- 2
- Contact Plating
- Tin
- Fabrika Tedarik Süresi
- 6 Weeks
- ECCN Kodu
- 5A991.B.1
- Max Input Current
- 20μA
- Protocol
- LVDS
- Lifecycle Status
- ACTIVE (Last Updated: 5 days ago)
- Differential Output
- NO
- Parça Durumu
- Active
- Montaj Tipi
- Surface Mount
- Temel Parça No
- DS90LV028
- JESD-609 Kodu
- e3
- Besleme Gerilimi
- 3V~3.6V
- Tip
- Receiver
- Input Characteristics
- DIFFERENTIAL
- Pin Sayısı
- 8
- Data Rate
- 400Mbps
- Uzunluk
- 4mm
- Terminal Pozisyonu
- DUAL
- Propagation Delay
- 2.5 ns
- Yükseklik
- 800μm
- Power Dissipation
- 3.3W
- Number Of Driversreceivers
- 0/2
- RoHS Durumu
- ROHS3 Compliant
- Supply Voltage1nom
- 3.3V
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Tepe Reflow Sıcaklığı (°C)
- 260
- Terminal Sayısı
- 8
- Kurşunsuz
- Lead Free
