Specifications
- Contact Plating
- Tin
- Montaj
- Surface Mount
- Çalışma Sıcaklığı
- -55°C~150°C TJ
- Uzunluk
- 3.3mm
- Continuous Drain Current Id
- 20A
- Gate Charge Qg Max Vgs
- 6.2nC @ 4.5V
- Radyasyon Dayanımı
- No
- Max Power Dissipation
- 6W
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 6 Weeks
- Terminal Adımı
- 0.65mm
- Nominal Vgs
- 1.4 V
- Kılıf / Paket
- 8-PowerLDFN
- Genişlik
- 3.3mm
- Rds On Max Id Vgs
- 9.6m Ω @ 14A, 8V
- Reach Svhc
- No SVHC
- Usage Level
- Military grade
- JESD-609 Kodu
- e3
- Turn Off Delay Time
- 15.8 ns
- Pin Sayısı
- 8
- Input Characteristics
- STANDARD
- Fet Type
- 2 N-Channel (Half Bridge)
- Turn On Delay Time
- 5.3 ns
- High Side Driver
- NO
- Temel Parça No
- CSD86330
- Yükseklik
- 1.5mm
- Parça Durumu
- Active
- Tepe Reflow Sıcaklığı (°C)
- 260
- Terminal Sayısı
- 8
- Drain To Source Voltage Vdss
- 25V
- Fet Feature
- Logic Level Gate
- Drain To Source Breakdown Voltage
- 25V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Gate To Source Voltage Vgs
- 8V
- Lifecycle Status
- ACTIVE (Last Updated: 4 days ago)
- Input Capacitance Ciss Max Vds
- 920pF @ 12.5V
- Vgsth Max Id
- 2.1V @ 250μA
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Contains Lead
