VERSAFIT-KIT-2-COLOR

Specifications

Category

Heat Shrink Tubing Kit

Flammability Rating

UL 224

Elv

Compliant

Montaj

Wall

Recovered Diameter

2.4 mm to 12.7 mm

Part Aliases

D54859-000

Fabrika Paket Adedi

4

Minimum Shrink Temperature

+ 70 C

RoHS Durumu

Non-RoHS Compliant

Maks. Çalışma Sıcaklığı

+ 135 C

Seri

Versafit

Çap

35 ea of 3/32 28 ea of 1/8 21 ea of 3/16 1/4 14 ea of 3/8 1/2

Parça Durumu

Active

Onay Kuruluşu

CSA, UL

Ürün Durumu

Discontinued at Digi-Key

Product Length Mm

152.4(mm)

Paket

Case

Min. Çalışma Sıcaklığı

-55°C

Maks. Çalışma Sıcaklığı

135°C

RoHS

Details

Birim Ağırlık

1.370 lbs

Shrinkage Ratio

2 to 1

Shrink Wall Type

THIN

Shrink Ratio

2:1

Minimum Operating Temperature

- 55 C

Yayın Yılı

1998

Chemical Resistant

Yes

Temel Ürün No

VERSAFIT

Nem Hassasiyeti (MSL)

Not Applicable

Tip

Single Wall Tubing Kit

Values

133 pcs - 6 (152.4mm) lengths

Ambalaj

Plastic Box with Bin Guide

Material

Polyolefin

Inside Diameter

5.21 mm to 25.53 mm

Operating Temp Range

-55C to 135C

Ürün Tipi

Heat Shrink Tubing and Sleeves

Fabrika Tedarik Süresi

22 Weeks

Uzunluk

152.4mm

Dielectric Strength

500 V/mil

Renk

Black, Blue, Clear, Green, Red, White, Yellow
