TXR40AB90-1008AI

Specifications

Parça Durumu

Active

Shielding

Shielded

Backshell Materialu2009

Aluminum

Fabrika Tedarik Süresi

26 Weeks

Thread Size

M15x1

Adapter Plating Materialu2009

Cadmium (AMS-QQ-P-416, Type II, Class 3)

Adapter Angleu2009

90

Cable Diameter Rangeu2009

6.4 – 10.2u2009mmu2009[u2009.25 – .4u2009inu2009]

Includes

6 pcs - 2 pc Backshell, 1 Braid, 2 O-Rings, 1 Tinel Ring

Wirecable Diameter

10.2 mm

Material

Aluminum Alloy

Ingress Protection

Environment Resistant

Kurşunsuz

Not Applicable

Elv

Non-Compliant

Min. Çalışma Sıcaklığı

-65°C

Seri

TXR

Shell Size Insert

11 B

Nem Hassasiyeti (MSL)

1 (Unlimited)

Plating

Cadmium

Te Internal Description

TXR40AB90-1008AI

Alias

1194823-7

Renk

Olive Drab

Özellikler

Tinel Lock

Yayın Yılı

2015

Ambalaj

Bulk

Lifecycle Status

ACTIVE (Last Updated: 2 days ago)

RoHS Durumu

Non-RoHS Compliant

Connector General Specification Numberu2009

MIL-DTL-38999 Series III/Class C,F,K,W, MIL-DTL-38999 Series IV/Class C,F,W, MIL-DTL-38999 Series IV/Class C,W, MIL-DTL-38999 Series IV/Class F,W

Cable Exit

90°

Tip

Backshell, Heat Shrink Adapter

Diameter Outside

0.827 (21.00mm)

Maks. Çalışma Sıcaklığı

175°C

Te Internal

609961-000
