Specifications
- Orientation
- Right Angle
- Empty Shell
- NO
- Shell Material
- Steel
- Depth
- 18.8mm
- Din Conformance
- NO
- Mating Connector Lock
- With
- Contact Materials
- Phosphor Bronze
- Contact Shape
- Round
- Reference Standard
- UL
- Pozisyon Sayısı
- 9
- Contact Type
- Signal
- Contact Finish Thickness
- 30.0μin 0.76μm
- High Temperature Housing
- Yes
- Uzunluk
- 30.81mm
- Number Of Pcb Rows
- 2
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Max Voltage Rating Dc
- 250.25kV
- Genişlik
- 12.55mm
- Shell Size Connector Layout
- 1 DE E
- Ambalaj
- Tray
- Connector Type
- Receptacle, Female Sockets
- Renk
- Black
- Connector Style
- D-Sub
- Flange Feature
- Housing/Shell (4-40)
- Mil Conformance
- NO
- Dielectric Material
- Polyamide (PA), Nylon
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Total Number Of Contacts
- 9
- Terminal
- Solder
- Akım Değeri
- 6A
- Sealable
- No
- Pitch
- 2.28mm
- Sıra Sayısı
- 2
- Gender
- Receptacle
- Nominal Gerilim
- 125V
- Parça Durumu
- Active
- Shell Finish
- TIN
- Seri
- AMPLIMITE HD-20
- Özellikler
- Board Lock
