Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Fabrika Tedarik Süresi
- 21 Weeks
- Mounting Angle
- Right Angle
- Montaj Tipi
- Through Hole
- Montaj Stili
- Board Lock
- Orientation
- 90° Angle (Right)
- Configuration
- 1x1
- Özellikler
- Board Lock
- Minimum Operating Temperature
- - 40 C
- Flammability Rating
- UL 94 V-0
- Contact Finish Thickness
- 30.0μin 0.76μm
- Parça Durumu
- Active
- Performance Category
- Cat 5
- Applications
- 10/100 Base-T, AutoMDIX
- Çalışma Sıcaklığı
- -40°C~85°C
- Gender
- Jack (Female)
- ECCN Kodu
- EAR99
- Ürün Tipi
- Modular Connectors / Ethernet Connectors
- REACH Uyumluluk Kodu
- compliant
- Number Of Cores Per Jack
- 4
- Housing Material
- Liquid Crystal Polymer (LCP)
- Lifecycle Status
- ACTIVE (Last Updated: 4 days ago)
- Yayın Yılı
- 2017
- RoHS Durumu
- RoHS Compliant
- Tip
- Magnetic Jack
- Sıra Sayısı
- 1
- Contact Finish
- Gold
- Connector Type
- RJ45
- Family
- Industrial Ethernet Products
- Number Of Positions Loaded
- 8
- HTS Kodu
- 8536.69.40.30
- Part Life Cycle Code
- Active
- Samacsys Description
- Modular Connectors / Ethernet Connectors RJ45 JACK INT.MAG. 10/100 LED 1X1
- Üretici Parça No
- 5-2301994-9
- Maks. Çalışma Sıcaklığı
- + 85 C
- Led Color
- Green, Yellow - Green, Yellow
- Contact Finish Mating
- NOT SPECIFIED
- Risk Rank
- 1.46
- Birim Ağırlık
- 0.246918 oz
- Fabrika Paket Adedi
- 50
