Specifications
- Nominal Current Rounded Value
- 5A
- Option
- GENERAL PURPOSE
- RoHS Durumu
- RoHS Compliant
- Reference Standard
- UL, CSA
- Plating Thickness
- 5.08μm
- Connections
- Cut & Clip
- Product Length
- 7.62 mm
- Material
- Polyamide
- Nominal Voltage
- 250V AC
- Din Conformance
- NO
- RoHS
- Details
- Üretici Parça No
- 3-643813-3
- Contact Materials
- COPPER ALLOY
- Housing Material
- Nylon
- Body Breadth
- 0.275 inch
- Contact Design
- PREASSEM CONN
- Voltage Rated Ac
- 250V
- Contact Finish
- Tin
- Body Depth
- 0.52 inch
- Max Temperature
- +105°C
- Pitch
- 0.100 2.54mm
- Flammability Rating
- UL94 V-2
- Insulator Color
- RED
- Özellikler
- Closed End
- Durability
- 25 Cycles
- Mil Conformance
- NO
- Minimum Operating Temperature
- -55°C
- Reach Svhc
- No SVHC
- Kurşunsuz Kodu
- yes
- Montaj Stili
- Cable
- Contact Resistance
- 6mOhm
- Yayın Yılı
- 2003
- Insulation Diameter
- 1.52 mm
- Ihs Manufacturer
- TE CONNECTIVITY LTD
- Fastening Type
- Locking Ramp
- Body Length
- 0.3 inch
- Max Cross Section
- 0.40mm²
- Contact Gender
- Female
- Contact Finish Termination
- Tin (Sn)
- Awg Max
- 22
