Specifications
- Mating Orientation
- Horizontal with Board
- Terminal And Terminal Block Type
- BARRIER STRIP TERMINAL BLOCK
- Number Of Ways
- 22
- Seri
- Buchanan
- Screw Thread
- M2.6
- Number Of Levels
- 1
- Nominal Gerilim
- 250V
- Pozisyon Sayısı
- 2
- Uzunluk
- 7mm
- Contact Plating
- Tin
- Screw Material Plating
- Steel, Galvanized - Chromate Plated
- Sıra Sayısı
- 1
- Safety Approval
- UL
- Max Current Rating
- 7A
- Yayın Yılı
- 2007
- RoHS Durumu
- RoHS Compliant
- Lifecycle Status
- ACTIVE (Last Updated: 3 days ago)
- Ambalaj
- Bulk
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 15 Weeks
- Renk
- Blue
- Voltage Rated Ac
- 200V
- Terminal
- Screw
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Parça Durumu
- Active
- Contact Material Plating
- Brass - Copper Tin Plated
- ECCN Kodu
- EAR99
- Circuit Applications
- Signal
- Wire Gauge
- 18-26 AWG
- HTS Kodu
- 8536.69.40.40
- Özellikler
- Interlocking (Side)
- Wirecable Gauge
- 18 AWG
- Contact Materials
- Brass
- Çalışma Sıcaklığı
- -55°C~105°C
- Additional Feature
- STANDARD: UL 94V-0, NYLON66
- Akım Değeri
- 7A
- Number Of Decks
- 1
- Wire Termination
- Screw - Leaf Spring, Wire Guard
- Housing Material
- Polyamide (PA66), Nylon 6/6
- Lead Pitch
- 3.5mm
