1-1546670-4

Specifications

Termination Method

Screw

Body Orientation

Straight

Number Of Decks

1

Pozisyon Sayısı

14

Mounting

Panel Mount

Montaj Stili

Open End Position

Terminal Screw Material

Steel

Seri

Buchanan

Thread Size

6-32 x 1/4

Number Of Ways

14

Wirecable Gauge

14 AWG

Wire Gauge Min

22 AWG

Fabrika Paket Adedi

50

Çalışma Sıcaklığı

-40°C~120°C

Max Current Rating

25A

Elv

Compliant

HTS Kodu

8536.69.40.40

Ambalaj

Bulk

Basehousing Material

PC (Polycarbonate)

RoHS

Details

Birim Ağırlık

3.891423 oz

Yayın Yılı

2007

Flammability Rating

UL94 V-0

Gerilim

300V

Nem Hassasiyeti (MSL)

1 (Unlimited)

Pitch

0.437 11.10mm

Number Of Wire Entries

28

ECCN Kodu

EAR99

Barrier Type

2 Wall (Dual)

Onay Kuruluşu

UL

Housing Color

Black

Akım Değeri

25A

Paket

Retail Package

Kurşunsuz

Lead Free

RoHS Durumu

RoHS Compliant

Wire Orientation

Vertical

Voltage Rating

300 V

Wire Size

22 to 14, 22 AWG

Ürün Durumu

Active

Mounting Angle

Vertical
