Specifications
- Yükseklik
- 9mm
- REACH Uyumluluk Kodu
- unknown
- Shielding
- Unshielded
- Voltage Isolation
- 500Vrms
- Seri
- PCA15EFD
- Turns Ratio Npns
- 1:1:1:1:1:1
- Primary Inductance
- 169 μH
- Packing Method
- TAPE & REEL
- ECCN Kodu
- EAR99
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 17.5mm
- Fonksiyon Sayısı
- 1
- Montaj
- Surface Mount
- Yayın Yılı
- 2006
- RoHS Durumu
- Non-RoHS Compliant
- Maks. Oturma Yüksekliği
- 0.354 9.00mm
- Inductance Frequency
- Parallel 169μH @ 10kHz Series 6.1mH @ 10kHz
- Footprint
- 0.713 L x 0.886 W (18.10mm x 22.50mm)
- Çalışma Sıcaklığı
- -40°C~85°C
- Parça Durumu
- Obsolete
- Boyut / Ölçü
- 0.713Lx0.630W 18.10mmx16.00mm
- Terminal
- Terminals
- Pin Sayısı
- 12
- Tip
- Configurable (For DC/DC)
- Physical Dimension
- L17.5XB15.5XH9.0 (mm)
- Applications
- Capacitor Charger
- Genişlik
- 15.5mm
- Et Productmin
- 47.4 V-us
- Montaj Tipi
- Surface Mount
- Additional Feature
- LENGTH DIMENSION INCLUDES TERMINAL ALSO
- Kurşunsuz
- Contains Lead
