PC95ELT20X7.7-Z

Specifications

Effective Area Ae Mm2

25.6

Gap

Ungapped

Material

PC95

Core Factor Ia Mm1

0.47

Tedarikçi Cihaz Paketi

ELT 20 x 7.7

Seri

Planar

Genişlik

16.00mm

Finish

Uncoated

Parça Durumu

Active

Core Type

ELH, PLT

RoHS Durumu

ROHS3 Compliant

Tolerans

±25%

Fabrika Tedarik Süresi

8 Weeks

Effective Length Le Mm

54.6

Uzunluk

20.00mm

Nem Hassasiyeti (MSL)

Not Applicable

Yükseklik

5.83mm

Effective Magnetic Volume Ve Mm3

1400

Inductance Factor Al

5.63μH

Minimum Core Cross Section Amin Mm2

52.9
