Specifications
- Case Code Imperial
- 1206
- Ambalaj
- Tape & Reel (TR)
- Kurşunsuz
- Lead Free
- Montaj
- Surface Mount
- Receive Center Frequency
- 2400MHz
- Montaj Tipi
- Surface Mount
- Case Code Metric
- 3216
- Return Loss Low Band High Band
- 15.0dB / 13.0dB
- Physical Dimension
- L3.2XB1.6XH1.3 (mm)/L0.126XB0.063XH0.051 (inch)
- Insertion Loss Rx
- 0.85 dB
- Kılıf / Paket
- 1206 (3216 Metric), 6 PC Pad
- Seri
- DPX
- Low Band Attenuation Min Max Db
- 18.00dB / -
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2004
- Uzunluk
- 3.2mm
- Genişlik
- 1.6mm
- Frequency Bands Low High
- 2.3GHz~2.5GHz / 4.9GHz~5.95GHz
- RoHS Durumu
- RoHS Compliant
- Insertion Loss Tx
- 1.2 dB
- Transmit Center Frequency
- 5425MHz
- Operating Temperature Max
- 85°C
- Operating Temperature Min
- -40°C
- Tip
- Diplexer
- Yükseklik
- 1.3mm
- High Band Attenuation Min Max Db
- 30.00dB / -
- Parça Durumu
- Obsolete
