Specifications
- Tcode
- T-1 3/4
- Parça Durumu
- Active
- HTS Kodu
- 8541.40.20.00
- Lens Type
- Diffused, White
- Wavelength Peak
- 565nm 627nm
- ECCN Kodu
- EAR99
- Mounting Feature
- RADIAL MOUNT
- Montaj Tipi
- Through Hole, Right Angle
- Lens Size
- 6.35mmx2.81mm
- Millicandela Rating
- 59mcd Green, 39mcd Red
- Viewing Angle
- 60°
- Luminous Intensity
- 39 mcd
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 6 Weeks
- Yayın Yılı
- 2013
- Yüzey Montaj
- NO
- Additional Feature
- IC COMPATIBLE, HIGH RELIABILITY
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Lens Style
- Rectangle with Flat Top
- Shape
- ROUND
- Kurşunsuz Kodu
- yes
- Terminal Sayısı
- 3
- Nominal Gerilim
- 2.2V Green 2V Red
- Akım
- 140mA Green 160mA Red
- Operating Temperature Min
- -40°C
- Fonksiyon Sayısı
- 1
- Overall Height
- 7.24mm
- Operating Temperature Max
- 85°C
- Renk
- Green, Red
- Configuration
- Single
- Terminal Adımı
- 2.54mm
- Packing Method
- BOX/BAG
- Optoelectronic Device Type
- DUAL COLOR LED
