STTH31AC06SPF

Specifications

Voltage Forward Vf Max If

2V @ 30A

Case Connection

ISOLATED

Ambalaj

Tube

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Applications

HIGH VOLTAGE ULTRA FAST SOFT RECOVERY

Nem Hassasiyeti (MSL)

1 (Unlimited)

Reverse Currentmax

10μA

Terminal Sayısı

3

Current Reverse Leakage Vr

10μA @ 600V

Voltage Dc Reverse Vr Max

600V

Additional Feature

SOFT FACTOR IS 2.2

ECCN Kodu

EAR99

Diode Type

Standard

Nonrep Pk Forward Currentmax

150A

Configuration

SINGLE

Reverse Recovery Time

65ns

Kılıf / Paket

TO-3P-3 Full Pack

Number Of Phases

1

Current Average Rectified Io

30A

Operating Temperature Max

175°C

Fabrika Tedarik Süresi

13 Weeks

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Output Currentmax

30A

Diode Element Material

SILICON

Jesd30 Code

R-PSFM-T3

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

Temel Parça No

STTH31

Montaj Tipi

Through Hole

Rep Pk Reverse Voltagemax

600V

RoHS Durumu

ROHS3 Compliant

Yüzey Montaj

NO

Operating Temperature Junction

175°C Max

Terminal Pozisyonu

SINGLE

Number Of Elements

1

Parça Durumu

Active
