Volume pricing
- 1+ pcs$0.55
- 10+ pcs$0.52
- 100+ pcs$0.49
- 500+ pcs$0.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Uzunluk
- 10.4mm
- Lifecycle Status
- ACTIVE (Last Updated: 7 months ago)
- Ambalaj
- Tube
- Case Connection
- CATHODE
- Voltage Forward Vf Max If
- 1.1V @ 15A
- Pin Sayısı
- 3
- Terminal Kaplaması
- Matte Tin (Sn)
- Peak Reverse Current
- 10μA
- Kılıf / Paket
- TO-220-2
- Fabrika Tedarik Süresi
- 11 Weeks
- Radyasyon Dayanımı
- No
- Reverse Voltage
- 200V
- Montaj
- Through Hole
- Min. Çalışma Sıcaklığı
- -65°C
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Forward Current
- 15A
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Reach Svhc
- No SVHC
- Number Of Elements
- 1
- Voltage Rated Dc
- 200V
- Peak Nonrepetitive Surge Current
- 150A
- Recovery Time
- 36 ns
- Element Configuration
- Single
- Current Reverse Leakage Vr
- 10μA @ 200V
- Terminal Sayısı
- 2
- Pin Sayısı
- 2
- Rms Current Irms
- 32A
- Akım Değeri
- 15A
- JESD-609 Kodu
- e3
- Output Current
- 15A
- Max Forward Surge Current Ifsm
- 150A
- Applications
- ULTRA FAST RECOVERY
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Genişlik
- 4.6mm
- Number Of Phases
- 1
- Reverse Recovery Time
- 36 ns
- Average Rectified Current
- 15A
- Additional Feature
- FREE WHEELING DIODE
- Natural Thermal Resistance
- 2.5 °C/W
