Specifications
- Maks. Çalışma Sıcaklığı
- 125°C
- Terminal Kaplaması
- Matte Tin (Sn) - annealed
- Seri
- SLLIMM™
- Pin Sayısı
- 38
- Tip
- IGBT
- Terminal Sayısı
- 38
- Fabrika Tedarik Süresi
- 12 Weeks
- Temel Parça No
- STGIPL14
- Configuration
- 3 Phase
- Collector Emitter Voltage Vceo
- 600V
- Akım
- 14A
- Lifecycle Status
- ACTIVE (Last Updated: 7 months ago)
- Turn On Time
- 400 ns
- Radyasyon Dayanımı
- No
- Min. Çalışma Sıcaklığı
- -40°C
- Kurşunsuz
- Lead Free
- Voltage Isolation
- 2500VDC
- Parça Durumu
- Active
- Turn Off Timenom Toff
- 425 ns
- Montaj Tipi
- Through Hole
- Yükseklik
- 8.55mm
- Turn Off Delay Time
- 320 ns
- Kılıf / Paket
- 38-PowerDIP Module (1.146, 29.10mm)
- Vcesatmax
- 2.5 V
- Max Power Dissipation
- 44W
- JESD-609 Kodu
- e3
- Reach Svhc
- No SVHC
- Transistor Application
- MOTOR CONTROL
- ECCN Kodu
- EAR99
- Terminal Pozisyonu
- DUAL
- Genişlik
- 25mm
- Collectoremitter Saturation Voltage
- 600V
- RoHS Durumu
- ROHS3 Compliant
- Uzunluk
- 50.1mm
- Max Junction Temperature Tj
- 150°C
- Min Supply Voltage
- 450V
- Montaj
- Surface Mount, Through Hole
- Turn On Delay Time
- 270 ns
- Max Supply Voltage
- 600V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
