SCT055W65G3-4AG

Specifications

Input Capacitance Ciss Max Vds

721 pF @ 40 V

Çalışma Sıcaklığı

-55°C ~ 200°C (TJ)

Vgs Max

+18V, -5V

Montaj Tipi

Through Hole

Ambalaj

Tube

Drain To Source Voltage Vdss

650 V

Fet Type

N-Channel

Kılıf / Paket

TO-247-4

Vgsth Max Id

4.2V @ 1mA

Rds On Max Id Vgs

72mOhm @ 15A, 18V

Gate Charge Qg Max Vgs

32 nC @ 18 V

Current Continuous Drain Id25

30A (Tc)

Parça Durumu

Active

Power Dissipation Max

210W (Tc)

Drive Voltage Max Rds On Min Rds On

15V, 18V

Qualification

AEC-Q101

Grade

Automotive

Tedarikçi Cihaz Paketi

TO-247-4
