Specifications
- Function
- Driver - Fully Integrated, Control and Power Stage
- Kurşunsuz
- Lead Free
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Genişlik
- 11mm
- Terminal Formu
- NO LEAD
- Motor Type Stepper
- Bipolar
- Pin Sayısı
- 102
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Logic Function
- AND
- Interface
- SPI
- Ambalaj
- Tape & Reel (TR)
- Applications
- General Purpose
- Terminal Pozisyonu
- QUAD
- Voltage Load
- 85V Max
- Terminal Sayısı
- 89
- Uzunluk
- 14mm
- Additional Feature
- OTHER NOMINAL VOLTAGE=5V
- Yüzey Montaj
- YES
- Kılıf / Paket
- 89-PowerVFQFN
- Analog Ic Other Type
- STEPPER MOTOR CONTROLLER
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Fabrika Tedarik Süresi
- 16 Weeks
- Output Voltage
- 85V
- RoHS Durumu
- ROHS3 Compliant
- Montaj Tipi
- Surface Mount
- Seri
- POWERSTEP
- Besleme Gerilimi
- 3.3V 5V
- ECCN Kodu
- EAR99
- Output Configuration
- Half Bridge (4)
- Operating Supply Voltage
- 85V
- Step Resolution
- 1 ~ 1/128
- HTS Kodu
- 8542.39.00.01
- Parça Durumu
- Active
- Besleme Gerilimi
- 3.3V
- Jesd30 Code
- R-XQCC-N89
