Specifications
- Montaj Tipi
- Surface Mount
- Max Duty Cycle
- 100 %
- Max Supply Current
- 9mA
- Terminal Kaplaması
- Nickel/Palladium/Gold (Ni/Pd/Au)
- Pin Sayısı
- 16
- Çıkış Tipi
- Transistor Driver
- Temel Parça No
- L6738
- Operating Supply Current
- 9mA
- Max Frequency
- 220kHz
- Output Configuration
- Positive
- Frequency Switching
- 200kHz
- Voltage Supply Vccvdd
- 5V~12V
- JESD-609 Kodu
- e4
- Function
- Step-Down
- Terminal Pozisyonu
- QUAD
- Analog Ic Other Type
- SWITCHING CONTROLLER
- Genişlik
- 3mm
- Kılıf / Paket
- 16-VQFN Exposed Pad
- RoHS Durumu
- ROHS3 Compliant
- Kurşunsuz
- Lead Free
- Control Mode
- VOLTAGE-MODE
- Ambalaj
- Tape & Reel (TR)
- Control Features
- Enable, Frequency Control, Phase Control, Power Good
- Fabrika Tedarik Süresi
- 12 Weeks
- Terminal Adımı
- 0.5mm
- ECCN Kodu
- EAR99
- Number Of Outputs
- 1
- Synchronous Rectifier
- Yes
- Lifecycle Status
- ACTIVE (Last Updated: 7 months ago)
- Qualification Status
- Not Qualified
- Nem Hassasiyeti (MSL)
- 3 (168 Hours)
- Topology
- Buck
- Terminal Formu
- NO LEAD
- Operating Supply Voltage
- 12V
- Uzunluk
- 3mm
- Input Voltage Min
- 5V
- Control Technique
- PULSE WIDTH MODULATION
- Çalışma Sıcaklığı
- -40°C~125°C TJ
- Terminal Sayısı
- 16
- Montaj
- Surface Mount
