Specifications
- ECCN Kodu
- EAR99
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Genişlik
- 1.05mm
- Applications
- HDMI
- Voltage Breakdown Min
- 4.5V
- Uzunluk
- 1.95mm
- Kapasitans
- 550FF
- RoHS Durumu
- ROHS3 Compliant
- Direction
- Unidirectional
- Montaj
- Surface Mount
- Max Reverse Leakage Current
- 100nA
- Çalışma Sıcaklığı
- -40°C~150°C TJ
- Reverse Standoff Voltage
- 5V
- Power Line Protection
- Yes
- Unidirectional Channels
- 4
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Peak Pulse101000s
- 1A 8/20μs
- Voltage Reverse Standoff Typ
- 3.6V
- Pin Sayısı
- 10
- Tip
- Steering (Rail to Rail)
- Seri
- HSP
- Capacitance Frequency
- 0.4pF @ 200MHz~2.5GHz
- Temel Parça No
- HSP051
- Fabrika Tedarik Süresi
- 11 Weeks
- Test Current
- 1mA
- Operating Supply Voltage
- 5V
- Lifecycle Status
- ACTIVE (Last Updated: 8 months ago)
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Clamping Voltage
- 10V
- Montaj Tipi
- Surface Mount
- Yükseklik
- 350μm
- Kılıf / Paket
- 10-XFDFN
- Ambalaj
- Tape & Reel (TR)
- Peak Pulse Current
- 1A
