Specifications
- Forward Voltage
- 510mV
- Diode Type
- FERD (Field Effect Rectifier Diode)
- Operating Temperature Junction
- 175°C Max
- Min. Çalışma Sıcaklığı
- -65°C
- Montaj
- Through Hole
- Terminal Pozisyonu
- SINGLE
- RoHS Durumu
- ROHS3 Compliant
- Lifecycle Status
- ACTIVE (Last Updated: 6 months ago)
- Kurşunsuz
- Lead Free
- Jedec95 Code
- TO-220AB
- Max Reverse Voltage Dc
- 45V
- Element Configuration
- Common Cathode
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- GENERAL PURPOSE
- Max Surge Current
- 300A
- Diode Configuration
- 1 Pair Common Cathode
- Maks. Çalışma Sıcaklığı
- 175°C
- Kılıf / Paket
- TO-220-3
- Voltage Forward Vf Max If
- 500mV @ 30A
- Speed
- Fast Recovery =< 500ns, > 200mA (Io)
- Radyasyon Dayanımı
- No
- Pin Sayısı
- 3
- Reverse Voltage Dc
- 45V
- Temel Parça No
- FERD60
- Fabrika Tedarik Süresi
- 15 Weeks
- Average Rectified Current
- 30A
- Forward Current
- 60A
- Max Repetitive Reverse Voltage Vrrm
- 45V
- Current Reverse Leakage Vr
- 1500μA @ 45V
- Diode Element Material
- SILICON
- Peak Nonrepetitive Surge Current
- 300A
- Ambalaj
- Tube
- ECCN Kodu
- EAR99
- Terminal Sayısı
- 3
- Peak Reverse Current
- 50mA
- Number Of Phases
- 1
- Montaj Tipi
- Through Hole
- Weight
- 2.299997g
- Number Of Elements
- 2
- Parça Durumu
- Active
