FERD20S100SH

Specifications

Voltage Dc Reverse Vr Max

100V

Diode Type

FERD (Field Effect Rectifier Diode)

Operating Temperature Junction

175°C Max

Terminal Pozisyonu

SINGLE

RoHS Durumu

RoHS Compliant

Lifecycle Status

NRND (Last Updated: 7 months ago)

Case Connection

CATHODE

Jesd30 Code

R-PSIP-T3

Tepe Reflow Sıcaklığı (°C)

NOT SPECIFIED

Reverse Currentmax

110μA

Nem Hassasiyeti (MSL)

1 (Unlimited)

Applications

EFFICIENCY

Configuration

SINGLE

Kılıf / Paket

TO-251-3, IPak, Short Leads

Voltage Forward Vf Max If

780mV @ 10A

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Yüzey Montaj

NO

Temel Parça No

FERD20

Rep Pk Reverse Voltagemax

100V

Operating Temperature Max

175°C

Forward Current

20A

Current Reverse Leakage Vr

100μA @ 100V

Diode Element Material

SILICON

Ambalaj

Tube

Terminal Sayısı

3

Number Of Phases

1

Montaj Tipi

Through Hole

Tepe Reflow Süresi (maks. sn)

NOT SPECIFIED

Parça Durumu

Obsolete

Number Of Elements

1
