Specifications
- Tepe Reflow Sıcaklığı (°C)
- NOT SPECIFIED
- Peak Reverse Current
- 20μA
- Parça Durumu
- Obsolete
- JESD-609 Kodu
- e3
- Tepe Reflow Süresi (maks. sn)
- NOT SPECIFIED
- Terminal Pozisyonu
- SINGLE
- ECCN Kodu
- EAR99
- Diode Type
- Standard - 1 Pair Series Connection
- Terminal Kaplaması
- Matte Tin (Sn)
- Max Current Rating
- 6A
- Çalışma Sıcaklığı
- 150°C TJ
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Applications
- HIGH VOLTAGE VERY FAST RECOVERY
- Diode Element Material
- SILICON
- Kapasitans
- 7pF
- Number Of Elements
- 2
- Akım Değeri
- 6A
- Temel Parça No
- DMV1500
- Jedec95 Code
- TO-220AB
- Jesd30 Code
- R-PSFM-T3
- Nonrep Pk Forward Currentmax
- 80A
- REACH Uyumluluk Kodu
- not_compliant
- Pin Sayısı
- 3
- Voltage Peak Reverse Max
- 1500V
- RoHS Durumu
- ROHS3 Compliant
- HTS Kodu
- 8541.10.00.80
- Terminal Sayısı
- 3
- Kurşunsuz
- Lead Free
- Number Of Phases
- 1
- Case Connection
- ISOLATED
- Reverse Voltage
- 600V
- Recovery Time
- 350 ns
- Yüzey Montaj
- NO
- Terminal Formu
- THROUGH-HOLE
- Max Surge Current
- 35A
- Ambalaj
- Tube
- Kılıf / Paket
- TO-220-3 Full Pack, Formed Leads
- Qualification Status
- Not Qualified
- Voltage Rated Dc
- 1.5kV
- Forward Voltagemax
- 1.4V
