Specifications
- Case Connection
- ISOLATED
- Contact Plating
- Tin
- Peak Pulse Current
- 39A
- Maks. Çalışma Sıcaklığı
- 175°C
- Montaj Tipi
- Through Hole
- Genişlik
- 3.53mm
- RoHS Durumu
- ROHS3 Compliant
- Operating Supply Voltage
- 28.2V
- Additional Feature
- UL RECOGNIZED
- Temel Parça No
- BZW04
- Number Of Elements
- 1
- Yükseklik
- 3.53mm
- Max Reverse Leakage Current
- 1μA
- Leakage Current
- 1μA
- Tip
- Zener
- Breakdown Voltage V
- 31.4V
- Parça Durumu
- Active
- Voltage Rated Dc
- 28V
- Seri
- BZW04, TRANSIL™
- Uzunluk
- 6.75mm
- Clamping Voltage
- 59V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Direction
- Bidirectional
- Kurşunsuz
- Lead Free
- ECCN Kodu
- EAR99
- Montaj
- Through Hole
- Terminal Formu
- WIRE
- Pin Sayısı
- 2
- Capacitance Frequency
- 255pF @ 1MHz
- Kılıf / Paket
- DO-204AC, DO-15, Axial
- Reverse Breakdown Voltage
- 31.4V
- Power Dissipation
- 1.7W
- Peak Pulse Power
- 400W
- Max Breakdown Voltage
- 31.4V
- Reverse Standoff Voltage
- 28.2V
- Test Current
- 1mA
- Reach Svhc
- No SVHC
- Power Line Protection
- No
- JESD-609 Kodu
- e3
- Fabrika Tedarik Süresi
- 11 Weeks
