Specifications
- Sıra Sayısı
- 1
- Seri
- MagJack® ST SI-50000
- Shield Material
- Copper Alloy
- Ambalaj
- Tray
- Parça Durumu
- Active
- Contact Finish Thickness
- 50.0μin 1.27μm
- Connector Type
- RJ45
- Housing Material
- Thermoplastic
- Pitch Mm
- 2.54(mm)
- Positions Loaded
- 8
- Number Of Positions Contacts Per Port
- 8P8C
- Tab Direction
- Up
- Flammability Rating
- UL 94 V-0
- Height Above Board
- 0.550 13.97mm
- Maks. Çalışma Sıcaklığı
- + 70 C
- Number Of Ports
- 1
- Paket
- Tray
- Terminal
- Solder
- Gender
- Female
- Number Of Cores Per Jack
- 8
- Termination Method
- Solder
- Screening Level
- COMMERCIALC
- RoHS Durumu
- ROHS3 Compliant
- Birim Ağırlık
- 0.428226 oz
- Applications
- 10/100/1000 Base-T, AutoMDIX
- Uzunluk
- 17.98mm
- Usoc Codes
- RJ45
- Terminal Stili
- Solder Pin
- Number Of Terminals
- 14
- Pitch
- 2.54mm
- Kılıf / Paket
- QFN
- Nem Hassasiyeti (MSL)
- Not Applicable
- Performance Category
- Cat 5e
- Tradename
- MagJack
- Fabrika Paket Adedi
- 50
- Tip
- RJ-45
- Led Color
- Green - Green, Yellow
- Family
- SI-51009-F
- Montaj Stili
- Surface Mount
- Number Of Contacts
- 8(POS)
