Volume pricing
- 1+ pcs$2.47
- 10+ pcs$2.33
- 100+ pcs$2.19
- 500+ pcs$2.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Maks. Çalışma Sıcaklığı
- 125°C
- Orientation
- Straight
- RoHS Durumu
- ROHS3 Compliant
- Yükseklik
- 13.3mm
- Contact Materials
- Phosphor Bronze
- Voltage Rated Ac
- 30V
- Flammability Rating
- UL94 V-0
- Terminal
- IDC
- Insulation Resistance
- 500MOhm
- Contact Resistance
- 10mOhm
- Cable Types
- Flat Oval Cable, Stranded Wires
- Wirecable Type
- Flat
- Contact Finish
- Gold
- Housing Material
- Polycarbonate (PC)
- Akım Değeri
- 1.5A
- Number Of Positionscontacts
- 4p4c (RJ9, RJ10, RJ22)
- Genişlik
- 7.6mm
- Number Of Contacts
- 4
- Wirecable Gauge
- 26 AWG
- Voltage Rated Dc
- 42V
- Contact Plating
- Gold
- Seri
- 30
- Nominal Gerilim
- 150V
- Min. Çalışma Sıcaklığı
- -40°C
- Pitch
- 1.02mm
- Ambalaj
- Bulk
- Shielding
- Unshielded
- Fabrika Tedarik Süresi
- 6 Weeks
- Parça Durumu
- Active
- Depth
- 7.62mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Cable
- Renk
- Translucent - Clear
- Current Rating Amps
- 1.5A
- Body Plating
- Gold
- Number Of Ports
- 1
- Uzunluk
- 0.525 13.34mm
- Yayın Yılı
- 1998
- Contact Finish Thickness
- 50.0μin 1.27μm
- Pozisyon Sayısı
- 4
