SI1014-C-GM2R

Specifications

Current Transmitting

17mA~30mA

Nem Hassasiyeti (MSL)

2 (1 Year)

Ambalaj

Tape & Reel (TR)

Qualification Status

Not Qualified

Memory Size

16kB Flash 768B RAM

Speed

25 MHz

Core Architecture

8051

Montaj Tipi

Surface Mount

Has Adc

YES

Yayın Yılı

2000

Serial Interfaces

I2C, SPI, UART

Modulation

FSK, GFSK, OOK

Number Of Ios

15

Watchdog Timers

Yes

Çalışma Sıcaklığı

-40°C~85°C

Power Supplies

1.8/3.6V

Besleme Gerilimi

1.9V

Terminal Sayısı

42

Pwm Channels

YES

Pin Sayısı

42

Parça Durumu

Not For New Designs

Terminal Adımı

0.5mm

Rambyte

768

Ram Size

768B

Besleme Gerilimi

1.8V~3.6V

Frekans

240MHz~960MHz

Kılıf / Paket

42-VFLGA Exposed Pad

Data Rate Max

256kbps

Terminal Formu

BUTT

Dma Channels

NO

Interface

I2C, SPI, UART

Tip

TxRx + MCU

Rf Familystandard

General ISM < 1GHz

Sensitivity Dbm

-121 dBm

Current Receiving

18.5mA

RoHS Durumu

RoHS Compliant

Uzunluk

7mm

Number Of Timerscounters

4

Protocol

EZRadioPro

Yüzey Montaj

YES
