Specifications
- Maks. Oturma Yüksekliği
- 34.92mm
- RoHS Durumu
- ROHS3 Compliant
- Onay Kuruluşu
- UL; CSA
- Max Output Current
- 260mA
- Kurşunsuz Kodu
- yes
- Seri
- PC
- Power Max
- 4.4VA
- Secondary Windings
- Dual
- Voltage Primary
- 115V
- Primary Windings
- Single
- Montaj Tipi
- Through Hole
- Nem Hassasiyeti (MSL)
- Not Applicable
- Uzunluk
- 41.3mm
- Terminal Stili
- PC Pin
- Voltage Isolation
- 1500Vrms
- Number Of Contacts
- 6
- Weight
- 0.313lb 141.97g
- Center Tap
- No
- Tip
- Laminated Core
- Output Voltage1
- 8V
- Yükseklik
- 34.9mm
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 16 Weeks
- Max Power Dissipation
- 4.4W
- Output Power
- 4.4W
- Yayın Yılı
- 2009
- Terminal
- PC Pin
- Frekans
- 500Hz
- Montaj
- Through Hole
- Genişlik
- 31.8mm
- HTS Kodu
- 8504.31.40.35
- Boyut / Ölçü
- 41.30mm Lx31.80mm W
- Output Voltage2
- 8V
- ECCN Kodu
- EAR99
- Kurşunsuz
- Lead Free
- Va Rating
- 4.4 VA
- Voltage Secondary Full Load
- Parallel 8V Series 16V
