Specifications
- Maks. Oturma Yüksekliği
- 95.30mm
- Output Voltage2
- 12V
- Primary Windings
- Single, Multiple Taps
- Power Max
- 288VA
- Montaj Tipi
- Chassis Mount
- Voltage Isolation
- 1500Vrms
- Terminal
- Solder
- Boyut / Ölçü
- 114.30mm Lx114.30mm W
- Montaj
- Chassis Mount
- Primary Rating
- SINGLE 105/115/125V
- Voltage Primary
- 105V 115V 125V
- Secondary Windings
- Dual
- Terminal Stili
- Solder, Quick Connect
- Additional Feature
- THE TWO SECONDARIES HAVE CENTER TAPPED CONNECTIONS
- Max Power Dissipation
- 288W
- Physical Dimension
- 114.3mm X 114.3mm X 95.3mm
- REACH Uyumluluk Kodu
- unknown
- ECCN Kodu
- EAR99
- RoHS Durumu
- ROHS3 Compliant
- Nem Hassasiyeti (MSL)
- Not Applicable
- Max Output Current
- 12A
- Uzunluk
- 114.3mm
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 14 Weeks
- Genişlik
- 114.3mm
- Output Voltage1
- 12V
- Voltage Secondary Full Load
- Parallel 12V Series 24V
- Tip
- Laminated Core
- Center Tap
- Yes
- Weight
- 11lbs 5kg
