Specifications
- Max Repetitive Reverse Voltage Vrrm
- 1.2kV
- Montaj
- Chassis Mount, Screw
- Diode Type
- Standard
- Diode Configuration
- 1 Pair Series Connection
- Current Average Rectified Io
- 90A DC
- Speed
- Standard Recovery >500ns, > 200mA (Io)
- Fabrika Tedarik Süresi
- 8 Weeks
- Nem Hassasiyeti (MSL)
- Not Applicable
- Tedarikçi Cihaz Paketi
- Module
- Ambalaj
- Bulk
- Pin Sayısı
- 3
- Isolation Voltage
- 2.5kV
- Peak Nonrepetitive Surge Current
- 1.95kA
- Voltage Rated Dc
- 1.2kV
- Voltage Forward Vf Max If
- 1.4V @ 270A
- Radyasyon Dayanımı
- No
- Maks. Çalışma Sıcaklığı
- 125°C
- Uzunluk
- 91.8972mm
- Kurşunsuz
- Lead Free
- Terminal
- Screw
- Yükseklik
- 30.3022mm
- Element Configuration
- Dual
- Voltage Dc Reverse Vr Max
- 1200V
- Voltage Rated Ac
- 480V
- Max Reverse Voltage Dc
- 1.2kV
- Forward Current
- 90A
- Montaj Tipi
- Chassis Mount
- RoHS Durumu
- RoHS Compliant
- Reach Svhc
- No SVHC
- Forward Voltage
- 1.4V
- Kılıf / Paket
- Module
- Operating Temperature Junction
- -40°C~125°C
- Akım Değeri
- 90A
- Min. Çalışma Sıcaklığı
- -40°C
- Parça Durumu
- Active
- Average Rectified Current
- 90A
- Genişlik
- 19.9898mm
