Volume pricing
- 1+ pcs$76.39
- 10+ pcs$72.07
- 100+ pcs$67.99
- 500+ pcs$64.14
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Boyut / Ölçü
- Square - 92mm Lx92mm H
- Özellikler
- PWM Control, Speed Sensor (Tach)
- Power Rating
- 5.04W
- Noise
- 44.0 dB(A)
- Rpm
- 5000 RPM
- Bearing Type
- Ball
- Seri
- San Ace 92W
- Voltage Range
- 10.8V~13.2VDC
- Güç (Watt)
- 5.04W
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Frame
- Aluminum
- Housing Material
- Aluminium
- Parça Durumu
- Active
- Static Pressure
- 0.420 in H2O (104.6 Pa)
- Weight
- 0.375lb 170.1g
- Onay Kuruluşu
- CSA, TUV, UL
- Nominal Gerilim
- 12VDC
- Genişlik
- 25.00mm
- Ingress Protection
- IP68 - Dust Tight, Waterproof
- Fan Type
- Tubeaxial
- Yayın Yılı
- 2014
- Lifetime Temp
- 180000 Hrs @ 60°C
- Fabrika Tedarik Süresi
- 16 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Material Blade
- Plastic
- Kılıf / Paket
- Axial
- Operating Supply Voltage
- 12V
- Akım Değeri
- 420mA
- Reach Svhc
- Unknown
- Current Rating Amps
- 0.420A
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Terminal
- 4 Wire Leads
