Specifications
- Voltage Range
- 10.8V~13.2VDC
- Ingress Protection
- IP68 - Dust Tight, Waterproof
- Rpm
- 5500 RPM
- Noise
- 43.0 dB(A)
- Güç (Watt)
- 3.6W
- Terminal
- 4 Wire Leads
- Power Rating
- 3.6W
- Material Frame
- Aluminum
- Boyut / Ölçü
- Square - 80mm Lx80mm H
- Lifetime Temp
- 180000 Hrs @ 60°C
- Yayın Yılı
- 2014
- Akım Değeri
- 300mA
- RoHS Durumu
- ROHS3 Compliant
- Özellikler
- PWM Control, Speed Sensor (Tach)
- Static Pressure
- 0.393 in H2O (98.0 Pa)
- Nominal Gerilim
- 12VDC
- Bearing Type
- Ball
- Nem Hassasiyeti (MSL)
- Not Applicable
- Material Blade
- Plastic
- Housing Material
- Aluminium
- Fabrika Tedarik Süresi
- 16 Weeks
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Parça Durumu
- Active
- Weight
- 0.331lb 150.14g
- Kılıf / Paket
- Axial
- Fan Type
- Tubeaxial
- Onay Kuruluşu
- CSA, TUV, UL
- Seri
- San Ace 80W
- Genişlik
- 25.00mm
- Current Rating Amps
- 0.300A
