Specifications
- Voltage Range
- 10.8V~13.2VDC
- Noise
- 47.0 dB(A)
- Rpm
- 15500 RPM
- Ingress Protection
- IP68 - Dust Tight, Waterproof
- Terminal
- 4 Wire Leads
- Güç (Watt)
- 4.8W
- Boyut / Ölçü
- Square - 40mm Lx40mm H
- Material Frame
- Aluminum
- RoHS Durumu
- ROHS3 Compliant
- Akım Değeri
- 400mA
- Yayın Yılı
- 2016
- Lifetime Temp
- 150000 Hrs @ 60°C
- Reach Svhc
- Unknown
- Özellikler
- PWM Control, Speed Sensor (Tach)
- Thermal Support Device Type
- DC FAN
- Nominal Gerilim
- 12VDC
- Static Pressure
- 1.245 in H2O (310.0 Pa)
- Bearing Type
- Ball
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Material Blade
- Plastic
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Fabrika Tedarik Süresi
- 16 Weeks
- Weight
- 0.154lb 69.85g
- Parça Durumu
- Active
- Kılıf / Paket
- Axial
- Fan Type
- Tubeaxial
- Onay Kuruluşu
- CSA, TUV, UL
- Current Rating Amps
- 0.400A
- Seri
- San Ace 40W
