Specifications
- Fan Type
- Tubeaxial
- Boyut / Ölçü
- Square - 80mm Lx80mm H
- Akım Değeri
- 460mA
- Noise
- 46.0 dB(A)
- Fabrika Tedarik Süresi
- 16 Weeks
- Static Pressure
- 0.574 in H2O (143.0 Pa)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Rating Amps
- 0.460A
- Bearing Type
- Ball
- Operating Supply Voltage
- 12V
- Material Blade
- Plastic
- Rpm
- 6700 RPM
- Material Frame
- Aluminum
- Onay Kuruluşu
- CSA, TUV, UL
- Parça Durumu
- Active
- Weight
- 0.287lb 130.18g
- Lifetime Temp
- 40000 Hrs @ 85°C
- Özellikler
- PWM Control, Speed Sensor (Tach)
- Kılıf / Paket
- Axial
- Terminal
- 4 Wire Leads
- Thermal Support Device Type
- DC FAN
- Seri
- San Ace 80T
- RoHS Durumu
- ROHS3 Compliant
- Voltage Range
- 10.2V~13.8VDC
- Nominal Gerilim
- 12VDC
- Yükseklik
- 80mm
- Power Rating
- 5.52W
- Reach Svhc
- Unknown
- Yayın Yılı
- 2002
- Housing Material
- Aluminium
- Çalışma Sıcaklığı
- -40~185°F -40°C~85°C
