Specifications
- Material Frame
- Plastic
- Material Blade
- Plastic
- Fan Type
- Tubeaxial
- Power Rating
- 11.16W
- Bearing Type
- Ball
- RoHS Durumu
- ROHS3 Compliant
- Voltage Range
- 10.2V~13.8VDC
- Lifetime Temp
- Varies Based on Temperature
- Boyut / Ölçü
- Square - 120mm Lx120mm H
- Fabrika Tedarik Süresi
- 16 Weeks
- Akım Değeri
- 930mA
- Terminal
- 4 Wire Leads
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Güç (Watt)
- 11.16W
- Noise
- 57.0 dB(A)
- Weight
- 0.617lb 280.00g
- Parça Durumu
- Active
- Static Pressure
- 1.470 in H2O (366.2 Pa)
- Özellikler
- PWM Control, Speed Sensor (Tach)
- Yayın Yılı
- 2017
- Genişlik
- 25.40mm
- Onay Kuruluşu
- cURus, TUV
- Nominal Gerilim
- 12VDC
- Rpm
- 6400 RPM
- Seri
- San Ace 120
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Current Rating Amps
- 0.930A
