Specifications
- Uzunluk
- 80mm
- Weight
- 0.176lb 79.83g
- Housing Material
- Plastic
- Özellikler
- PWM Control, Speed Sensor (Tach)
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Static Pressure
- 0.110 in H2O (27.4 Pa)
- Genişlik
- 20.00mm
- Nominal Gerilim
- 12VDC
- Onay Kuruluşu
- CSA, TUV, UL
- Yayın Yılı
- 2014
- Yükseklik
- 80mm
- Çalışma Sıcaklığı
- -4~158°F -20°C~70°C
- Seri
- San Ace 80
- Rpm
- 2900 RPM
- Reach Svhc
- Unknown
- Current Rating Amps
- 0.060A
- Fan Type
- Tubeaxial
- Maks. Çalışma Sıcaklığı
- 70°C
- Material Frame
- Plastic
- Material Blade
- Plastic
- Boyut / Ölçü
- Square - 80mm Lx80mm H
- Fabrika Tedarik Süresi
- 16 Weeks
- Depth
- 80mm
- Bearing Type
- Ball
- Power Rating
- 720mW
- Lifetime Temp
- 60000 Hrs @ 60°C
- Voltage Range
- 10.2V~13.8VDC
- RoHS Durumu
- ROHS3 Compliant
- Akım Değeri
- 60mA
- Min. Çalışma Sıcaklığı
- -10°C
- Noise
- 26.5 dB(A)
- Terminal
- 4 Wire Leads
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Güç (Watt)
- 720mW
- Kılıf / Paket
- Axial
