Volume pricing
- 1+ pcs$2.15
- 10+ pcs$2.03
- 100+ pcs$1.92
- 500+ pcs$1.81
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 3 Weeks
- Number Of Positions Loaded
- All
- Additional Feature
- E.L.P.
- Iec Conformance
- NO
- Connector Type
- Header
- Parça Durumu
- Active
- Ambalaj
- Bulk
- Filter Feature
- NO
- Reach Svhc
- No SVHC
- Option
- GENERAL PURPOSE
- Contact Finish Mating
- Gold
- Contact Materials
- Phosphor Bronze
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Shape
- Square
- Material Flammability Rating
- UL94 V-0
- Insulation Color
- Black
- Montaj
- Through Hole
- Pitch Mating
- 0.100 2.54mm
- Contact Finish Thickness Mating
- 3.00μin 0.076μm
- Montaj Tipi
- Through Hole
- Yayın Yılı
- 2005
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Din Conformance
- NO
- Contact Finish Post
- Tin
- Sıra Sayısı
- 2
- Style
- Board to Board or Cable
- JESD-609 Kodu
- e3
- Shrouding
- Unshrouded
- Kurşunsuz Kodu
- yes
- Contact Type
- Male Pin
- Seri
- TSW
- Terminal
- Solder
- Row Spacing Mating
- 0.100 (2.54mm)
- Fastening Type
- Push-Pull
- Contact Length Post
- 0.110 2.79mm
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Contact Lengthmating
- 0.320 8.13mm
- Mil Conformance
- NO
- Insulation Height
- 0.100 2.54mm
- Overall Contact Length
- 0.530 13.46mm
