Volume pricing
- 1+ pcs$1.34
- 10+ pcs$1.26
- 100+ pcs$1.19
- 500+ pcs$1.12
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Polyester
- JESD-609 Kodu
- e3
- Kurşunsuz Kodu
- yes
- Terminal
- Solder
- Seri
- TSW
- Genişlik
- 2.54mm
- Contact Type
- Male Pin
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Insulation Height
- 0.119 3.02mm
- Radyasyon Dayanımı
- No
- Orientation
- Right Angle
- Gender
- Male
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 0 Weeks
- Number Of Positions Loaded
- All
- Max Voltage Rating Ac
- 450V
- Iec Conformance
- NO
- Connector Type
- Header
- Option
- GENERAL PURPOSE
- Reach Svhc
- No SVHC
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Materials
- Phosphor Bronze
- Contact Finish Mating
- Gold
- Montaj
- Through Hole
- Contact Shape
- Square
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Pitch Mating
- 0.100 2.54mm
- Style
- Board to Board or Cable
- Din Conformance
- NO
- Contact Finish Post
- Tin
- Shrouding
- Unshrouded
- Max Current Rating
- 7.6A
- Contact Length Post
- 0.090 2.29mm
- Fastening Type
- Push-Pull
- Uzunluk
- 38.1mm
- Mil Conformance
- NO
- Contact Lengthmating
- 0.230 5.84mm
- Mixed Contacts
- NO
- Lead Pitch
- 2.54mm
- Pozisyon Sayısı
- 15
