Volume pricing
- 1+ pcs$0.53
- 10+ pcs$0.50
- 100+ pcs$0.47
- 500+ pcs$0.44
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Voltage Rating Ac
- 550V
- Row Spacing Mating
- 0.100 (2.54mm)
- Radyasyon Dayanımı
- No
- Number Of Positions Loaded
- All
- Kurşunsuz Kodu
- yes
- Style
- Board to Board or Cable
- Mil Conformance
- NO
- Fastening Type
- Push-Pull
- Contact Shape
- Square
- Din Conformance
- NO
- Montaj
- Through Hole
- Connector Type
- Header
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mixed Contacts
- NO
- Fabrika Tedarik Süresi
- 3 Weeks
- Pozisyon Sayısı
- 10
- Contact Materials
- Phosphor Bronze
- Seri
- TSW
- Parça Durumu
- Active
- Lead Pitch
- 2.54mm
- Contact Length Post
- 0.115 2.92mm
- RoHS Durumu
- ROHS3 Compliant
- Gender
- Male
- Max Current Rating
- 7.6A
- Çalışma Sıcaklığı
- -55°C~105°C
- Contact Lengthmating
- 0.265 6.73mm
- Contact Finish Mating
- Tin
- Ambalaj
- Bulk
- Terminal
- Solder
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Depth
- 5.08mm
- Additional Feature
- E.L.P.
- Insulation Color
- Black
- Material Flammability Rating
- UL94 V-0
- Housing Material
- Polyester
- Option
- GENERAL PURPOSE
- Yayın Yılı
- 2005
- Insulation Height
- 0.100 2.54mm
- Ul Flammability Code
- 94V-0
