Volume pricing
- 1+ pcs$1.75
- 10+ pcs$1.65
- 100+ pcs$1.56
- 500+ pcs$1.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Overall Contact Length
- 0.480 12.19mm
- Contact Lengthmating
- 0.250 6.35mm
- Number Of Conductors
- ONE
- Shrouding
- Shrouded - 4 Wall
- Body Breadth
- 0.365 inch
- Depth
- 9.27mm
- Reach Svhc
- No SVHC
- Uzunluk
- 27.94mm
- Montaj Tipi
- Through Hole
- Mixed Contacts
- NO
- Sıra Sayısı
- 2
- Contact Type
- Male Pin
- Contact Length Post
- 0.115 2.92mm
- Radyasyon Dayanımı
- No
- Orientation
- Straight
- RoHS Durumu
- ROHS3 Compliant
- Gender
- Male
- Pcb Contact Pattern
- RECTANGULAR
- Din Conformance
- NO
- Connector Type
- Header
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Finish Mating
- Tin
- Material Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- Çalışma Sıcaklığı
- -55°C~105°C
- Pozisyon Sayısı
- 16
- Fabrika Tedarik Süresi
- 3 Weeks
- Housing Material
- Polyester
- Insulation Color
- Black
- Terminal
- Solder
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Polarization Key
- POLARIZED HOUSING
- Option
- GENERAL PURPOSE
- Insulation Materials
- Polybutylene Terephthalate (PBT), Glass Filled
- Insulation Resistance
- 5000000000Ohm
- Contact Shape
- Square
- Fastening Type
- Push-Pull
- Max Current Rating
- 3A
- Iec Conformance
- NO
