Specifications
- Ul Flammability Code
- 94V-0
- ECCN Kodu
- EAR99
- Insulation Materials
- Polybutylene Terephthalate (PBT)
- Mating Contact Pitch
- 0.1 inch
- Number Of Pcb Rows
- 2
- RoHS Durumu
- ROHS3 Compliant
- Reference Standard
- UL
- Gender
- Male
- Orientation
- Straight
- Radyasyon Dayanımı
- No
- Insulation Height
- 0.350 8.89mm
- Reliability
- COMMERCIAL
- JESD-609 Kodu
- e3
- Housing Material
- Polyester
- Rated Current Signal
- 3A
- Insulation Resistance
- 5000000000Ohm
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Type
- Male Pin
- Seri
- Flex Stack, TSS
- Terminal
- Solder
- Contact Shape
- Square
- Contact Finish Mating
- Tin
- Contact Materials
- Phosphor Bronze
- Çalışma Sıcaklığı
- -55°C~105°C
- Mounting Option1
- LOCKING
- Din Conformance
- NO
- Style
- Board to Board or Cable
- Pitch Mating
- 0.100 2.54mm
- Number Of Positions Loaded
- All
- Fabrika Tedarik Süresi
- 4 Weeks
- Reach Svhc
- No SVHC
- Polarization Key
- POLARIZED HOUSING
- Option
- GENERAL PURPOSE
- Pcb Contact Pattern
- RECTANGULAR
- Connector Type
- Header
- Iec Conformance
- NO
- Uzunluk
- 54.61mm
- Fastening Type
- Push-Pull
- Contact Length Post
- 0.115 2.92mm
- Pozisyon Sayısı
- 40
