TSM-109-04-T-SV

Specifications

Additional Feature

E.L.P.

Number Of Pcb Rows

2

Reference Standard

UL

Reliability

COMMERCIAL

Terminal

Solder

Shrouding

Unshrouded

Contact Type

Male Pin

Pitch Mating

0.100 2.54mm

JESD-609 Kodu

e3

Connector Type

Header

Mixed Contacts

NO

Kurşunsuz Kodu

yes

Seri

TSM

Contact Shape

Square

Sıra Sayısı

1

Pozisyon Sayısı

9

Fabrika Tedarik Süresi

3 Weeks

Option

GENERAL PURPOSE

Number Of Positions Loaded

All

Insulation Resistance

5000000000Ohm

Pcb Contact Pattern

STAGGERED

Plating Thickness

200μin

Montaj Tipi

Surface Mount

Material Flammability Rating

UL94 V-0

Filter Feature

NO

Ambalaj

Tube

Number Of Conductors

ONE

Iec Conformance

NO

Parça Durumu

Active

Çalışma Sıcaklığı

-55°C~105°C

Yayın Yılı

2012

Montaj

Surface Mount

Contact Materials

Phosphor Bronze

Insulation Color

Black

Insulation Materials

Liquid Crystal Polymer (LCP)

Contact Finish Mating

Tin

Terminal Adımı

2.54mm

RoHS Durumu

ROHS3 Compliant

Din Conformance

NO

Style

Board to Board or Cable
