TSM-109-01-S-SH

Specifications

Terminal

Solder

Shrouding

Unshrouded

Pitch Mating

0.100 2.54mm

Additional Feature

E.L.P.

Number Of Pcb Rows

1

Reference Standard

UL

Kurşunsuz Kodu

yes

Seri

TSM

Contact Shape

Square

Pozisyon Sayısı

9

Mixed Contacts

NO

Connector Type

Header

Contact Finish Thickness Mating

30.0μin 0.76μm

Number Of Positions Loaded

All

Option

GENERAL PURPOSE

Iec Conformance

NO

Çalışma Sıcaklığı

-55°C~125°C

Yayın Yılı

2012

Material Flammability Rating

UL94 V-0

Ambalaj

Tube

Number Of Conductors

ONE

Insulation Materials

Liquid Crystal Polymer (LCP)

Uzunluk

22.86mm

Contact Materials

Phosphor Bronze

Insulation Color

Black

Kurşunsuz

Lead Free

Terminal Adımı

2.54mm

Style

Board to Board or Cable

Din Conformance

NO

Max Voltage Rating Ac

475V

Fastening Type

Push-Pull

Insulation Height

0.120 3.05mm

Max Current Rating

7A

Orientation

Right Angle

Contact Type

Male Pin

JESD-609 Kodu

e3

Reliability

COMMERCIAL

Sıra Sayısı

1

Radyasyon Dayanımı

No

Fabrika Tedarik Süresi

3 Weeks
