Volume pricing
- 1+ pcs$0.92
- 10+ pcs$0.87
- 100+ pcs$0.82
- 500+ pcs$0.77
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Montaj Tipi
- Through Hole
- Orientation
- Straight
- Insulation Height
- 0.100 2.54mm
- Filter Feature
- NO
- Mating Contact Pitch
- 0.05 inch
- Fastening Type
- Push-Pull
- Contact Finish Mating
- Gold
- Din Conformance
- NO
- Contact Lengthmating
- 0.100 2.54mm
- Montaj
- Through Hole
- Contact Length Post
- 0.120 3.05mm
- Row Spacing Mating
- 0.100 (2.54mm)
- Contact Finish Thickness Post
- 3.00μin 0.076μm
- Mixed Contacts
- NO
- Contact Materials
- Phosphor Bronze
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Plating Thickness
- 10μin
- Sıra Sayısı
- 2
- Fabrika Tedarik Süresi
- 3 Weeks
- Insulation Color
- Black
- Number Of Pcb Rows
- 2
- Contact Finish Thickness Mating
- 10.0μin 0.25μm
- Yayın Yılı
- 2012
- Reach Svhc
- No SVHC
- Iec Conformance
- NO
- Contact Type
- Male Pin
- Style
- Board to Board
- Current Rating Amps
- 5A per Contact
- Connector Type
- Header
- Option
- GENERAL PURPOSE
- Max Current Rating
- 1A
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Gender
- Male
- Number Of Positions Loaded
- All
- Çalışma Sıcaklığı
- -55°C~125°C
- Number Of Conductors
- ONE
- Material Flammability Rating
- UL94 V-0
- Reference Standard
- UL
- Seri
- TMS
